1.Water demand: water supply pressure: ≥ 1 kg.f/cm2, water supply diameter: 20mm, drainage pipe diameter: 50 mm, water consumption: 150L/H
2.The temperature of each section: the main washing water temperature: 60-75 °C, the final flush water temperature: 80-95 °C
3.Water tank capacity: 35L
Device capabilities
1.Single cylinder main washing, the whole machine cleaning, disinfection integration effect is more thorough, improve the turnover rate of dishes.
2. Reliable all stainless steel transmission system, equipped with overload automatic protection device, compact structure, save space.
3.The water pump is imported from Italy, which is not affected by temperature, enhances the jet strength of the water flow, and ensures the washing effect.
4.CPU computer board control system, easy to operate, water tank and heater automatic water injection, automatic water level control, to ensure normal operation, automatic temperature control device to maintain a constant temperature.
The main material of the equipment
1.Electrical components: (leakage) circuit breaker, contactor, thermal relay to choose ABB or Schneider brand; buttons, indicators, intermediate relays to choose Japan Omron, French Schneider, ABB and other brands,
2.The heater chooses the Italian brand, power: 9KW, 4.5KW
3.The main washing pump, rinsing pump to choose the original Italian import, power: 0.75KW
4.The main washing system, rinsing system, equipment support, guard plate, water cylinder, nozzle, electrical box, all screws and other materials are national standard 304 stainless steel, stainless steel square specifications: 38×38×1.5mm, water cylinder plate thickness: 2.0 mm; guard plate thickness: 1.2 mm.
Washing effect
The main washing water temperature: 60-75 ° C, through the main washing area with the dishwasher special cleaner can clean all residues and oil stains on the tableware; finally the water temperature: 80-95 ° C with the dishwasher special drying agent; can make the tableware dry quickly, in line with national security use standards.
